Wacom PL-1600

Wacom PL-1600

Wacom PL-1600 Interactive Pen Display

The Wacom PL-1600 Series interactive Pen Displays enable users to add handwritten input directly to the 15–22-inch monitors using a digital pen. They are therefore particularly suited for the presentation of full-page documents including the direct insertion of signatures. This provides solutions for applications where the contractual text needs to be depicted, for example when signing a telecoms contract or a contract ate a banking counter. The Wacom PL-1600 Interactive Pen Display are available in a range of sizes and can therefore be selected to suit any circumstance.

signature-display-PL-1600-angle-left-no-screen
Wacom PL-1600

The Wacom PL-1600 15.6 Inch Tablet has been designed for those, who want to combine the advantage of an pen tablet with a high-quality LCD display – to boost productivity and ergonomics at the workplace.

The Wacom PL-1600 Interactive Pen Display enable users to add handwritten input directly to the 15-22 inch monitors using a digital pen. They are therefore particularly suited for the presentation of full-page documents including the direct insertion of signatures. This provides solutions for applications where the contractual text needs to be depicted, for example when signing a telecoms contract or a contract ate a banking counter. The PL-series of interactive pen displays are available in a range of sizes and can therefore be selected to suit any circumstance.

Looking for a flexible solution that lets you change environments easily with your mobile equipment? The PL-1600 is the perfect choice to enrich your style of advertising. It features a wide HD screen and a portable, compact 16″ format. Simply connect memory keys or other peripherals to the USB ports wherever you are. Because today’s audiences are accustomed to a different, more interactive kind of media usage and consumption, Wacom has developed a contemporary, effi cient presentation tool that helps to simplify any kind  of knowledge transfer, whether in business or education:

• Enriches presentation methods
• The PL-1600 allows comments to be written by pen directly on the screen which makes your presentation more lively.
• With its compact 16″ widescreen HD display, it’s the ideal mobile solution for users who change their teaching environments frequently.
• The PL-1600 promotes a motivating and fruitful face-to-face working  atmosphere between presenter and listeners.
• Enjoy perfect hand-eye coordination and ergonomic posture.

General Specifications
  • Dimensions
    420 x 283 x 49 mm
  • Weight
    4,3 kg
  • Power supply
    AC 100 to 240 V, 50/60 Hz
  • Power consumption
    29 W or less with AC adapter, 2 W or less in sleep mode,
    1 W or less in off mode
  • Communication interface
    USB
  • Supported operating systems
    Windows® 8, 7, Vista, Vista x64, XPTM (excl x64 version), Mac OS X 10.6.8 or later
LCD Screen
  • Main body colour
    dark grey
  • Display
    F-STN, monochrome, reflective
  • Cover plate surface
    Tempered anti-glare etched glass with anti-reflective coating
  • Screen diagonal
    346 mm x 195 mm (13.6 x 7.7 in)
  • Resolution
    1.366 x 768
  • Viewing angles (horizontal/vertical)
    45°/45°, 20°/65°
  • Colours
    16.7 Million colours
  • Response time
    8 ms (typical)
Pad & Pen
  • Technology
    Electromagenetic resonance (EMR)
  • Active area
    346,2 x 195,5 mm
  • Resolution
    2540 lpi or 0,01 mm/point
  • Coordinate accuracy
    ±0.02 inch / 0.5 mm (center)
  • Report rate
    133 points/second, max.
  • Pressure levels
    1024
Miscellaneous
  • Reading height
    0.2 inch / 5 mm (center)
  • Pen storage
    Integrated pen compartment, pen holder
  • Software
    Compatible with signature / e-signing software and Wacom´s sign I pro PDF,C++,.
    Net and Java SDK/API available for developers
  • Package content
    Signature pad, battery-free & cordless pen, pen tether, USB cable 1.5m,
  • Operating temperature,relative humidity
    +5° to +35°C / +41° F to +95° F, 20% to 80% (non-condensing)
  • Storage temperature,relative humidity
    -10° to +60°C / -14° F to +140° F, 20% to 90% (non-condensing)
  • Warranty
    Depending on region and channel of purchae – please inquire for details
